The testo 327-1 Flue Gas Analyser offers a robust and simple entry into flue gas analysis for domestic boilers. It measures O2 & CO and will calculate ratio, CO2, etc. The 4-line LED display can be configured to the user's requirements, and its back-lighting function guarantees an easy-to-read display even if lighting conditions are unfavourable. The analyser stands out on account of its easy menu navigation and ergonomic housing as well as its durability.
Delivery Scope
testo 327 Flue Gas Analyser, rechargeable battery and calibration protocol, Flue Gas Probe (180mm x 6mm diameter), Pressure hose connection kit, Differential temperature kit (2 x pipe clamp probes), testo infrared printer, soft carry case with shoulder strap, AC power supply.
Specification
Testo 327-1 Multi-Purpose Flue Gas Analyser Advanced Kit Specification
Temperature - TC Type K (NiCr-Ni)
Measuring range
-40.00 to +600.00 °C
Accuracy
±0.50 °C (0 to 99.90 °C) ±0.50 % of mv (100 to 600 °C)
Resolution
0.1 °C
Reaction time
< 50 s
Flue gas O2
Measuring range
0 to 21 Vol.%
Accuracy
±0.2 Vol.%
Resolution
0.1 Vol.%
Reaction time t90
30 s
Differential Pressure flue gas Draught - Piezoresistive
Measuring range
-40.0 to +40.0 hPa
±0.03 hPa (-3.00 to +3.00 hPa)
Accuracy
±0.02 hPa (-0.50 to +0.60 hPa)
±0.03 hPa (+0.61 to +3.00 hPa)
±1.50 hPa (3.01 to +40.0 hPa)
Resolution
0.01 hPa
Flue gas degree of effectivity, Eta (calculated)
Measuring range
0 to 120 %
Resolution
0.1 %
Flue gas loss (calculated)
Measuring range
0 to 99.0 %
Resolution
0.1 %
Flue gas CO2 calculation (calculated from O2)
Measuring range
0 to CO2 max (Display range)
Accuracy
±0.2 Vol.%
Resolution
0.1 Vol.%
Reaction time t90
< 40 s
Flue gas CO (without H2-compensation)
Measuring range
0 to 4000 ppm
Accuracy
±20 ppm (0 to 400 ppm)
±5 % of mv (401 to 2000 ppm)
±10 % of mv (2001 to 4000 ppm)
Resolution
1 ppm
Reaction time t90
60 s
General technical data
Weight
(with probe) Approx. 700 g
Dimensions
201 x 83 x 44 mm
Operating temperature
-5 to +45 °C
Display type
LCD (Liquid Crystal Display)
Display function
Backlit 2-line display
Power supply
Battery: 1500 mAh, mains unit 5V/1A
Storage temperature
-20 to +50 °C
Features
Testo 327-1 Multi-Purpose Flue Gas Analyser Advanced Kit Features
4,000ppm CO sensor with automatic pump shut off to help prevent saturation
7 user-selectable fuels
Rechargeable Li-ion battery
Adaptors and accessories for pressure measurement and differential temperature clamp probes supplied
Testo IR printer
Soft carry case with shoulder strap
