With Testo 300 Flue Gas Analyser Advanced Kit, you will be equipped for the most important measurements involving heating systems: the EN 50379, Parts 1-3 compliant testo 300 flue gas analyser is supplied with O2 and 4,000ppm CO sensor, basic flue gas probe, soft-case style instrument bag with carrying handle, 2 x pipe clamps for differential temperature, pressure connection set. If required, a testo fast Bluetooth printer 0554 0621 can be used to give a local printout of measured values (printer NOT supplied in this kit).
Delivery Scope
testo 300 flue gas analyser with O2 and CO sensor up to 4,000 ppm (0633 3002 70)
USB mains unit, including cable (0554 1105)
Compact basic flue gas probe, 180 mm, Ø 6 mm, Tmax. 500°C; 1.5 m hose; including cone for fixing (0600 9740)
2 x clamp probes (NTC) for temperature measurements on pipes (Ø 6-35 mm) with fixed cable (cable length 1.4 m) (0615 5505)
Pressure connection kit with 2 silicone hoses (Ø 6 mm and Ø 4 mm, each 1 m long) and measuring instrument adapter for testo 300 (0554 1203)
Soft-case style Instrument bag (0516 3001)
Typical lead time may be 2-3 weeks. Please contact us to get a more exact delivery date.
Specification
Testo 300 Flue Gas Analyser Advanced Kit Specification
Flue gas measurement on heating systems
Ideal for measurements involving heating systems:
high-quality sensors, smart-touch operation, clearly structured measurement menus, creation of documentation on-site, e-mailing of reports, large HD display, robust housing
Further areas of application:
gas flow pressure measurement*, gas pipe test*, differential temperature measurement (flow and return temperature on heating systems)*, ambient CO measurement*, flue draught measurement on heating systems*, integrated 4 Pa measurement for combustion equipment
* Please note: additional probes or accessories are required for these measurements and have to be ordered separately.
Features
Testo 300 Flue Gas Analyser Advanced Kit Features
Intuitive measurement menus and fast-response Smart-Touch display
Including O2 and CO sensors up to 4,000 ppm
3rd sensor slot to allow optional Nitric Oxide (NO) sensor to be fitted to allow the device to give calculated NOx measurement (sensor 0393 0151 required)
